ZONESUN ZS-FS009A Full Automatic Liquid Paste Aluminum Tube Filling Sealing Machine
ZONESUN ZS-FS009A Full Automatic Liquid Paste Aluminum Tube Filling Sealing Machine
정가
$12,499.00 USD
정가
할인가
$12,499.00 USD
단가
단위
배송료는 결제 시 계산됩니다.
픽업 사용 가능 여부를 로드할 수 없습니다.
DESCRIPTION
This filling sealing machine combines filling structure,sealing structure at one rotary workbench,it is designed for packaging aluminium tube products like toothpaste,hand cream,ointment etc.
PARAMETER
|
Machine model
|
ZS-FS009A
|
|
Machine voltage
|
220/380V 2.6KW
|
|
Filling pump
|
Piston pump
|
|
Filling accuracy
|
±1%
|
|
Working speed
|
20-50 pieces/min
|
|
Filling volume
|
6-75ml/20-150ml/50-300ml
(according to production need)
|
|
Aluminium tube length
|
60-220mm(Can be customized)
|
|
Aluminium tube diameter
|
φ13-40mm
|
|
Air pressure
|
0.55-0.65MPa
|
|
Machine size
|
About 2150*950*2000mm
|
|
Machine weight
|
About 600kg
|
PRODUCT DETAILS
The touch screen control panel makes working data visual, this is more convenient to debug machine and watch the working status in real time.Different kinds of operation language can be customized as needed.
The tube feeding structure can ensure the aluminium tube will be place into tube holder smoothly and orderly, it reduces working error and labor.
Equipped with piston pump and pneumatic filling nozzles, this is more powerful when filling thicker liquid and paste.
The number of sealing structure can be customized according to production need.The folding width at the sealing can be adjusted as needed.Extra date coding machine can be equipped with to print batch number or production date
The number of sealing structure can be customized according to production need.The folding width at the sealing can be adjusted as needed.Extra date coding machine can be equipped with to print batch number or production date
